(Assy.) SF/ST/LN/24/MW/83S/MV/WH/BLS 24" Linear Strip Light, Selectable CCT and Wattage with Bi-Level Sensor

Mouse over the image to zoom. Double-tap and hold to zoom.

(Assy.) SF/ST/LN/24/MW/83S/MV/WH/BLS 24" Linear Strip Light, Selectable CCT and Wattage with Bi-Level Sensor

Product Code: 85621-SU

Specifications

15/20/25 Watts
CCT Selectable
2060/2742/3167 Lumens
24"
1
120-277 Volts
ETL - Damp Location
See all specs

Specifications

General Characteristic

Base:
Average Rated Hours:	50000
Dimmable:	1
Dimming Type:	0-10V Low Voltage
Dimming Percentage:	10-100%
Fixture Material:	Steel
Lens Material:	Polycarbonate
Lens Finish:	White
Application:	Commercial, Industrial, Residential

Electrical Characteristic

Watts:	15/20/25
Volts:	120-277
Equivalent Wattage:	2-T8
LED Chip Manufacturer:
Power Factor:	.9
Temperature:	-4°F - 120°F

Lighting Characteristic

Lumens Brightness:	2060/2742/3167
Color Rendering Index (CRI):	80
R9 Rating:
Emitted Color:	CCT Selectable
Color Temperature Kelvin:	35K/40K/50K
Beam Angle:	140x110

Product Dimensions

Size:	24"
Item Dimension:	(W) 2.61 (H) 2.65 (D) 23.94
Package Dimension:	(W) (H) (D)
Package Weight:
Canopy Width In:
Cord Length:

Product Data

Case Unit Rate:	6.000000
Item UPC:	653703856216
Warranty Years:	5

Additional Features

Safety Rating Mark:	ETL - Damp Location
Safety Rated for USA:	1
Safety Rated for Canada:	1
DLC Approved:	True
DLC Classification:	S-4FPTN6, S-8UOHVT
ROHS Compliant:	0
Mercury Free:	0
IC Rated:	0

More Information

Shape:	Linear
Number Of Lights:
Mounting:	Surface
Fixture Technology:	Integrated LED
Use Location:	Indoor
